• Specs

  Key Specifications:

  • Operating Weight: 17,200 ± 300 kg
  • Rated Payload: 5,500 kg
  • Bucket Capacity: 3.6 m³
  • Rated Power: 162 kW @ 2,200 rpm
  • Engine: Weichai WP10G220E21 Diesel
  • Fuel Tank Capacity: 280 L




  Performance & Operation

  • Bucket Capacity: 3.6 m³
  • Rated Payload: 5,500 kg
  • Traction Force: 165 kN
  • Breakout Force: 175 ± 5 kN
  • Travel Speed (Forward): 23.5 – 25.3 km/h
  • Travel Speed (Reverse): 13.5 km/h
  • Dimensions (L × W × H): 8,320 × 3,000 × 3,400 mm




  Engine Specifications

  • Make / Model: Weichai WP10G220E21
  • Rated Power: 162 kW @ 2,200 rpm
  • Max Torque: 860 N·m @ 1,400 – 1,600 rpm
  • Displacement: 9.726 L (6 Cylinders)
  • Bore × Stroke: 126 mm × 130 mm
  • Air Cleaner: Three-stage
  • Alternator: 70 A
  • Battery: 2 × 24V / 120 Ah
  • Starter Motor: 24V / 7.5 kW




  Transmission

  • Type: Planetary Powershift
  • Control: Mechanical Powershift
  • Pressure: 1.1 – 1.5 MPa
  • Torque Converter: Single-stage, double turbine, 4-element




  Brake System

  • Service Brake: Single circuit caliper, dry type
  • Operating Pressure: 0.70 – 0.78 MPa
  • Parking Brake: Air-actuated caliper
  • Emergency Brake: Air-actuated caliper




  Steering System

  • Type: Hydraulic load sensing
  • Pump Flow: 165 L/min @ 2,200 rpm
  • System Pressure: 15 MPa
  • Cylinder: Double-acting
  • Steering Angle: ±35°




  Hydraulic System

  • Type: Double pump confluence
  • Pump Flow: 207 L/min @ 2,200 rpm
  • Control Valve: 2 spool
  • System Pressure: 19 MPa
  • Cycle Time: 11 seconds
  • Hydraulic Tank: 180 L (165 L with 3rd spool)




  Service Refill Capacities

  • Fuel Tank: 280 L
  • Hydraulic Tank: 180 L
  • Engine Oil: 17 L
  • Transmission: 48 L
  • Front Axle: 28 L
  • Rear Axle: 28 L




  Dimensions

  • Overall Length (with bucket): 8,320 mm
  • Width over Bucket: 3,000 mm
  • Height to Cab: 3,400 mm
  • Height (Bucket Raised): 6,560 mm
  • Bucket Pin Height: 4,164 mm
  • Dump Clearance (45°): 3,100 mm
  • Wheelbase: 3,350 mm
  • Ground Clearance: 398 mm
  • Turning Radius (Tires): 6,650 mm
  • Turning Radius (Bucket): 7,386 mm
